Why it’s all about location, location, location for civil engineers

Date
01 July 2020

Engineers of all disciplines need Geographic Information Systems (GIS) for the very simple reason that geospatial data makes projects faster, better, and more cost effective.

Why it’s all about location, location, location for civil engineers
GIS is frequently the only solution which can examine diverse elements within a single system (image credit: Shutterstock)

One of the first pieces of GIS Analysis was performed amidst an outbreak of cholera in London’s Soho district in 1854. The transmission mechanism for the disease was unknown at the time, so the evidence to investigate was constrained to the people who had fallen ill.

John Snow, an early epidemiologist was the first recorded person to treat this data as spatial data. He interviewed residents to understand key interactions with local environmental factors, including water pumps in the area. He put patients on a map and undertook Voronoi analysis [a spatial pattern technique] to draw a link between a single water pump and the illness, and further substantiated his findings by showing an anomaly; nearby brewery workers who should have been falling ill at the same rate were spared by their daily beer allowance, which enabled them to avoid the problem pump.

His findings are commonly cited within Health Geography, but rarely enter an engineering syllabus, despite his further geospatial work comparing practices of various waterwork engineering companies.

The key learning point for engineers today is that if Snow had been working with merely a list of patients, he would have had no opportunity to link that list with the deadly water pump and it could have remained a medical mystery and a worsening tragedy. So where else can geospatial data uncover hidden value?

Finding a Context

Whether you deal in utility networks, transportation, energy production or telecoms, your project has a location (grid coordinate, depth, height), or perhaps even a moving location, which is even more important to manage well. When an object has a location, it allows you to discover, explore, analyse and interact with its context of multiple, delicate interdependencies on built and natural environmental elements both inside and external to the project elements themselves. This might be demography, geomorphology, utility grid issues, flood forecasting, mobile phone pings of a moving population, bat records; the list goes on.

Manage these diverse elements poorly and you’ll find your project blocked at planning, poorly used once complete, inefficient to operate or perhaps just really difficult at end-of-life disposal stage. Multi-discipline project teams will come to loggerheads over mutually exclusive design decisions, construction teams will despair over how to implement environmental mitigation, and valuable information will be obfuscated at every data exchange point.

GIS (Geographic Information Systems) is of course only one tool to prevent this kind of chaos, but it’s a very important one, and one that’s frequently overlooked or seen as a competitor rather than a colleague or player within other data management systems such as BIM. Given that the big software houses on both sides are becoming increasingly intertwined, here are a few ways you as an engineer can interact with GIS and implement it in workflows;

Layered insight

Due to the diversity of elements within the environmental context of a project, GIS is frequently the only solution which can examine them all within a single system, by looking at their sole unifying factor; their location. GIS can instantly count how many trees with bat potential sit within 20km of a site or calculate the population who would suffer power outages in the event of substations flooding. It can calculate energy use baselines for a whole town on the journey to Net Zero, or identify every viewpoint impacted by development of a new road. Adding layers of data enables powerful analysis to be carried out.

Automating to unlock insights

GIS really lends itself to automation, via integration with sophisticated Python data Libraries such as NumPy and SciPy, as well as the use of licensed tools such as FME. Using these tools allows GIS specialists to build reusable tools for iterative analysis and data processing tasks ranging from multi-sheet Compulsory Purchase Order drawings for infrastructure development to networking tasks for water utilities. As above, by using multiple data sources, these insights can be updated based on changes in the surrounding area, not just changes within your own project. Having an iterative source of insight into these outside changes will enable you to easily pinpoint and manage risk from externalities providing a more realistic view.

Crack your data management

Many of the burgeoning document management systems, such as Projectwise, don’t yet handle spatial data files well. However GIS as a sector has adapted to this technological drawback by building new links between systems to facilitate better cross-project data management. A Spatial Common Data Environment, as we have developed at Atkins, provides a single-source-of-truth for spatial data, with visualisation tools such as 3D and 2D WebGIS already built in, to give a whole-project window for the full team. Using automated versioning, GIS can automatically allow design fixes to be shared with multi-disciplinary teams within, for example, a DCO process, helping to get deliverables done on time and with minimal rework.

GI-Yes for Engineers – a match made in Data?

Atkins recently won accolades for their work in Geospatial led design, where geospatial data on environmental constraints was considered first before a single engineer got to work. The resulting linear infrastructure centre line options handed to its civil engineers achieved the maximum avoidance of environmental, heritage and socioeconomic assets, speeding up delivery and reducing costs dramatically.

There is more data available than ever, ripe for GIS use. As our industries continue to develop digital processes, we will all need to use as much data as we can lay our hands on, and geospatial consultants alongside engineers can be the ideal partnership to ensuring this happens.

ICE is currently seeking to expand its network of subject matter experts in Geospatial Engineering. If you are interested in taking an active role in this development to exchange and build knowledge with like-minded professionals in geospatial engineering, please email us.

  • Elspeth McIntyre PIEMA AMICE, Geospatial Consultant, Atkins
